Digital Pressure Gauge ACD-108mini

Short Description:

Digital pressure gauge ACD-108mini is battery powered with good shock resistance. It can measure gas, liquid and other media, suitable for portable equipment, metrical instrument and pipeline indoor.

Send email to us

Product Detail

Product Tags

Details

Main Features	Large-screen LCD display, back light, high resolution, easy to read
	Automatically record the maximum pressure values during the measurement
	Dynamic display of pressure percentage (progress bar display)
	Five engineering units：psi、bar、kpa、kg/c㎡、MPa
	1 ~ 15min auto-off feature
	Micro power consumption, working in power-saving mode for more than 2 years, continuous working for 2000 hours
	Parameter correction, correct zero and error on site
	Sampling Rate：4 times/s
	Applicable to gas and liquid compatible with stainless steel

Main Parameters	Measuring Range	-0.1MPa～0～100MPa	Accuracy	0.2%F.S、0.5%F.S
	Overload Capacity	150%F.S	Pressure Type	G/A/D Pressure
	Stability	≤0.1%F.S /年	Battery	9V DC
	Display Mode	4 Digits LCD	Display Range	-1999～9999
	Environmental Temperature	-20℃~70℃	Relative Humidity	0~90%
	Note：cooling element shall be used when medium temperature exceeds 80℃

Overall Dimensions (Unit: mm)

Selection Guide

Selection Guide of ACD-108mini Digital Pressure Gauge
ACD-108mini
Installation Mode	J	Radial
	Z	Axial
Thread Connection		G12	G1/2
		M20	M20*1.5
		M27	M27*2
Measuring Range			According to customer’s request
