Digital Temperature Gauge ACT-108mini
Details
|
Main Features |
Large screen LCD with high resolution and no collimation error. | |||
| Peak value record function. | ||||
| Progress bar display. | ||||
| 1~15min auto power-off. | ||||
| Micro-power consumption supports 2000 hours constant working time in power-saving mode. | ||||
| Parameters correcting, null point and error could be amended on the broad. | ||||
| Sample rate: 1 time/s. | ||||
|
Main Parameters |
Measuring Range | -200℃~500℃ | Accuracy | 0.2%F.S, 0.5%F.S |
| Stability | ≤0.1%F.S /year | Temperature Sensor | PT100 | |
| Display Mode | 4 Digits LCD | Display Range | -1999~9999 | |
| Battery | 9V DC | Connector Material | Stainless Steel | |
| Environmental Temperature | -20℃~70℃ | Relative Humidity | 0~90% | |
Overall dimensions(Unit:mm)
Selection Guide
|
Selection Guide of ACT-108mini Digital Temperature Gauge |
|||||
| ACT-108mini | |||||
| InstallationMode | J | Radial | |||
| Z | Axial | ||||
| Thread Connection | G12 | G1/2 | |||
| M20 | M20*1.5 | ||||
| M27 | M27*2 | ||||
| Measuring Range | According to customer’s request | ||||
| Insert Depth | L...mm | ||||
